Prostar PIH8K-96 pure sine wave 96V 8kW power inverter is an electronic device or circuitry that changes direct current (DC) to alternating current (AC).
Prostar PIH8K-96 pure sine wave 96V 8kW power inverter is an electronic device or circuitry that changes direct current (DC) to alternating current (AC). The input voltage, output voltage and frequency, and overall power handling depend on the design of the specific device or circuitry. The inverter does not produce any power; the power is provided by the DC source.
Prostar pure sine wave 96V 8kW power inverter can be entirely electronic or may be a combination of mechanical effects (such as a rotary apparatus) and electronic circuitry. Static inverters do not use moving parts in the conversion process.
Prostar pure sine wave 96V 8kW power inverter is capable of producing 110Vac/120Vac/220Vac/230Vac. It will work virtually anywhere in the world, with the ability to auto detect 50Hz or 60Hz.
96v inverter built-in charger allows for you to use your existing grid power to maintain a charge on your batteries.
Prostar pure sine wave 96V 8kW power inverter which produces a multiple step sinusoidal AC waveform is referred to as a sine wave inverter. To more clearly distinguish the inverters with outputs of much less distortion than the modified sine wave inverter designs. Almost all consumer grade inverters that are sold as a “pure sine wave inverter” do not produce a smooth sine wave output at all, just a less choppy output than the square wave and modified sine wave inverters. However, this is not critical for most electronics as they deal with the output quite well.
Where power inverter devices substitute for standard line power, a sine wave output is desirable because many electrical products are engineered to work best with a sine wave AC power source. The standard electric utility provides a sine wave, typically with minor imperfections but sometimes with significant distortion.
|Voltage Range||100V/110V/120V/127AC or 208V/220V/230V/240VAC(+25%,-36%)|
|Frequency Range||50/60 Hz±2.5Hz Auto|
|AC Voltage Regulation||100V/110V/120V/127AC±0.5% or 208V/220V/230V/240VAC±0.5%（AC Mode±10%）|
|Frequency||50HZ/60HZ±0.5HZ Auto（AC Mode±2.5HZ）|
|Transfer Time||8ms default, 4ms optional|
|Floating Charge Voltage||108.8VDC|
|AC Charge Current||1A-20A Adjustable (20A default)|
|Output Short Circuit||AC mode:Jump fuse, Inverter mode: Shut down|
|Overload||Full load 100%, Inverter alarm. Overload 120%, Inverter shut down output in 10s. Once the load back to normal, Inverter recover output.|
|High AC Voltage||Turn off AC,turn to Inverter mode automatically|
|Low DC Voltage||Inverter shut down automatically,Once the AC recover, Inverter turn on and charge automatically|
|Over Temperature||Power Off|
|Temperature||-10℃ ~ 50℃|
|Communication||USB, RS232, 485, SNMP (Optional)|
|Dimension, DxWxH (mm)||535*280*525|
|Net Weight (Kgs/PC)||53.50|
|Product specifications are subject to change without further notice.|
