48vdc telecom dc to ac power inverter 4000w

Prostar PIR4K rack mount 48vdc telecom dc to ac power inverter 4000w

Rack-mount Power Inverter | 4KW | 3U | 48VDC | 110V/120V or 220V/230V/240V | Single Phase

SKU: PIR4K Category:

Prostar PIR4K rack mount 48vdc telecom dc to ac power inverter 4000w is a stand-alone inverter capable of converting a 48V DC power source into a pure sine wave AC output.

It mounts neatly and out of the way on racks but will automatically switch from your local electric utility to your backup batteries when city power fails during storms or power outages are caused by other factors.

Prostar rack-mount inverter selection runs the gamut. From 300W 12VDC inverters and 4000W 48V DC inverters, we have you covered. Rack sizes include 2u and 3u.

Prostar Rack-mount Power Inverter

Rack-mount power inverter technology

Prostar PIR4K rack mount 48vdc telecom dc to ac power inverter 4000w produces high-quality, pure sine power at a stable 110V/120V or 220V/230V/240V AC output that is ideal for running sensitive electronics. It is perfect for computers, telecom, audio/visual, medical and other important equipment. Another way to better secure your critical loads.

A built-in automatic transfer switch seamlessly transfers power from your city service to your battery backup bank when city power goes out, with a typical transfer time of less than 8 ms. As long as your battery backups provide sufficient voltage, the telecom dc to ac power inverter 4000w will provide steady power to your devices.

AC outlets give you easy access to AC power. DC terminals are on the back of the inverter for connecting to battery power. The front of the inverter has a LED monitor and LCD display that lets you track input DC voltage, output AC voltage, frequency and AC current. A communications port allows you to monitor these numbers via computer as well.

Features & Benefits

1. Excellent microprocessor control guarantees high reliablility

2. Intelligent charger with adjustable charging voltage and charging current

3. Wide input voltage range (110V-300V)

4. Special Protection method

5. Well unattended function

6. Auto restart while AC is recovering

7. Pure Sine Wave Output

8. Boost and buck AVR for voltage stabilization

9. Cold start function

10. LCD panel for comprehensive display

Diagram of Power Inverter 4000w

Rack-mount power inverter diagram

Inverter Details

Rack-mount power inverter details

Rack-mount power inverter LCD display

Rack-mount power inverter display icons

Rack-mount power inverter rear detail

Rack-mount power inverter 4000w provides a neat, organized and dependable way to protect your essential equipment from blackouts and other emergencies and city utility power problems.

Inverter Smart Charger

Rack-mount power inverter smart charging

Inverter Offers Mult-protection Function

Rack-mount power inverter protection function

The Articles You may Like

    Request Product Price



    * Required

    Technical Data of Power Inverter 4000W

    ModelPIR4K
    Rated Power4000W
    INPUT
    Voltage Range100V/110V/120V/127AC or 208V/220V/230V/240VAC(+25%,-36%)
    Frequency Range50/60 Hz±2.5Hz Auto
    OUTPUT
    AC Voltage Regulation100V/110V/120V/127AC±0.5% or 208V/220V/230V/240VAC±0.5%(AC Mode±10%)
    Frequency50HZ/60HZ±0.5HZ Auto(AC Mode±2.5HZ)
    Surge Power12KW
    Battery Efficiency81%
    AC Efficiency93%
    Transfer Time8ms default, 4ms optional
    WaveformPure Sinewave
    BATTERY
    Battery Voltage48VDC
    Floating Charge Voltage54.4VDC
    Overcharge Protection60.0VDC
    AC Charge Current0-40A Adjustable (40A default)
    PROTECTION
    Battery ReversalOptional
    Output Short CircuitAC mode:Jump fuse, Inverter mode: Shut down
    OverloadFull load 100%, UPS alarm. Overload 120%, inverter shut down output in 10s. Once the load back to normal, inverter recovers output.
    High AC VoltageTurn off AC, turn to inverter mode automatically
    Low DC VoltageInverter shuts down automatically, once the AC recover, inverter turns on and charges automatically
    Over TemperaturePower Off
    ENVIRONMENT
    Humidity15~93%(No condensation)
    Temperature-10℃ ~ 50℃
    Altitude≤3000m
    CommunicationRS232(default),USB, RS485, SNMP (Optional)
    MECHANICAL SPECIFICATIONS
    Dimension, DxWxH (mm)483×420×132 [3U]
    Net Weight (Kgs/PC)33.00
    Product specifications are subject to change without further notice.
